SPMRT Positionable Male Run Tees
3 Items in SPMRT Positionable Male Run Tees
side-scroll to see full table
 |
|
| |
| Part# | SPMRT 4-4U | SPMRT 6-6U | SPMRT 6-6U |
| Information | |||
| Type |
Male Tee |
Male Tee |
Male Tee |
| Part Number |
SPMRT 4-4U |
SPMRT 6-6U |
SPMRT 6-6U |
| Dimensions | |||
| Dimension A |
15.24mm |
16.76mm |
16.76mm |
| Dimension B |
17.78mm |
19.30mm |
19.30mm |
| Dimension C |
16.51mm |
20.07mm |
20.07mm |
| Dimension I |
21.08mm |
24.64mm |
24.64mm |
| Dimension L |
28.45mm |
32.00mm |
32.00mm |
| Dimension L1 |
28.45mm |
32.26mm |
32.26mm |
| Dimension d [Min] |
4.83mm |
7.11mm |
7.11mm |
| End Size |
44028in |
43359in |
43359in |
| Tube Outside Diameter D |
1/4in |
3/8in |
3/8in |
| Width Across Flats H |
9/16in |
11/16in |
11/16in |
| Width Across Flats h1 |
1/2in |
5/8in |
5/8in |
| Width Across Flats h2 |
9/16in |
11/16in |
11/16in |
| Specifications | |||
| End Type |
Society of Automotive Engineering (SAE)/MS Straight Thread |
Society of Automotive Engineering (SAE)/MS Straight Thread |
Society of Automotive Engineering (SAE)/MS Straight Thread |
| Inch/Metric |
Inch |
Inch |
Inch |
| Material |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
| Description |
SPMRT 1/4 in. x 7/16-20 Society of Automotive Engineering (SAE) Straight Thread Positionable Male Run Tee with O-Ring |
SPMRT 3/8 in. x 9/16-18 Society of Automotive Engineering (SAE) Straight Thread Positionable Male Run Tee with O-Ring |
SPMRT 3/8 in. x 9/16-18 Society of Automotive Engineering (SAE) Straight Thread Positionable Male Run Tee with O-Ring |
