SMA Male Adapters
Male Adapter Tube Fittings are commonly used in different industrial sectors such as: Manufacturing, Aero Space, Process Piping. These Fittings have a Tube Stub on one side and Male threads on the other. These fitting allow customers to make connections to female threaded fitting and valves. The tube stube portion of the fitting is inserted into a compression tube fitting and is secured once the nut is turned 1 and ¼ turns from finger tight. Making directional changes in a line is easily accomplished using the tube stub portion of these fittings.
Downloads
22 Items in SMA Male Adapters
side-scroll to see full table
 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
| |
| Part# | SMA 2-2N | SMA 2-4N | SMA 3-2N | SMA 4-2N | SMA 4-4N | SMA 4-6N | SMA 4-8N | SMA 6-2N | SMA 6-4N | SMA 6-6N | SMA 6-8N | SMA 8-4N | SMA 8-6N | SMA 8-8N | SMA 10-6N | SMA 10-8N | SMA 10-12N | SMA 12-8N | SMA 12-12N | SMA 12-16N | SMA 16-12N | SMA 16-12N |
| Information | ||||||||||||||||||||||
| Type |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
Male Adapter |
| Part Number |
SMA 2-2N |
SMA 2-4N |
SMA 3-2N |
SMA 4-2N |
SMA 4-4N |
SMA 4-6N |
SMA 4-8N |
SMA 6-2N |
SMA 6-4N |
SMA 6-6N |
SMA 6-8N |
SMA 8-4N |
SMA 8-6N |
SMA 8-8N |
SMA 10-6N |
SMA 10-8N |
SMA 10-12N |
SMA 12-8N |
SMA 12-12N |
SMA 12-16N |
SMA 16-12N |
SMA 16-12N |
| Dimensions | ||||||||||||||||||||||
| Dimension L |
29.50mm |
34.80mm |
30.22mm |
31.80mm |
37.08mm |
37.84mm |
43.43mm |
33.50mm |
38.90mm |
39.60mm |
45.20mm |
44.5mm |
45.20mm |
50.80mm |
47.40mm |
52.3mm |
52.3mm |
52.3mm |
52.3mm |
57.91mm |
58.70mm |
58.70mm |
| Dimension d [Min] |
4.82mm |
7.11mm |
4.82mm |
4.4mm |
4.4mm |
4.4mm |
4.4mm |
4.82mm |
6.9mm |
6.9mm |
6.9mm |
7.11mm |
9.4mm |
9.4mm |
9.90mm |
12.00mm |
14.98mm |
11.94mm |
14.8mm |
20.32mm |
15.74mm |
15.74mm |
| Dimension d1 |
2.10mm |
2.10mm |
3.04mm |
4.40mm |
4.40mm |
4.40mm |
4.40mm |
6.90mm |
6.90mm |
6.90mm |
6.90mm |
9.40mm |
9.40mm |
9.40mm |
12.00mm |
12.00mm |
12.00mm |
14.80mm |
14.80mm |
14.80mm |
20.40mm |
20.40mm |
| End Size |
44204in |
44200in |
44204in |
44204in |
44200in |
44263in |
44198in |
44204in |
44200in |
44263in |
44198in |
44200in |
44263in |
44198in |
44263in |
44198in |
44259in |
44198in |
44259in |
1in |
44259in |
44259in |
| Tube Outside Diameter D |
1/8in |
1/8in |
3/16in |
1/4in |
1/4in |
1/4in |
1/4in |
3/8in |
3/8in |
3/8in |
3/8in |
1/2in |
1/2in |
1/2in |
5/8in |
5/8in |
5/8in |
3/4in |
3/4in |
3/4in |
1in |
1in |
| Width Across Flats h |
7/16in |
9/16in |
7/16in |
7/16in |
9/16in |
11/16in |
7/8in |
7/16in |
9/16in |
11/16in |
7/8in |
9/16in |
11/16in |
7/8in |
11/16in |
7/8in |
1-1/16in |
7/8in |
1-1/16in |
1-3/8in |
1-1/16in |
1-1/16in |
| Specifications | ||||||||||||||||||||||
| End Type |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
Male National Pipe Thread (NPT) |
| Inch/Metric |
Inch |
Inch |
Inch |
Inch |
Inch |
Inch |
Inch |
Inch |
Inch |
Inch |
Inch |
Inch |
Inch |
Inch |
Inch |
Inch |
Inch |
Inch |
Inch |
Inch |
Inch |
Inch |
| Material |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
316 Stainless Steel |
| Description |
SMA 1/8 in. Tube Stub x 1/8 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 1/8 in. Tube Stub x 1/4 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 3/16 in. Tube Stub x 1/8 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 1/4 in. Tube Stub x 1/8 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 1/4 in. Tube Stub x 1/4 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 1/4 in. Tube Stub x 3/8 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 1/4 in. Tube Stub x 1/2 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 3/8 in. Tube Stub x 1/8 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 3/8 in. Tube Stub x 1/4 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 3/8 in. Tube Stub x 3/8 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 3/8 in. Tube Stub x 1/2 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 1/2 in. Tube Stub x 1/4 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 1/2 in. Tube Stub x 3/8 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 1/2 in. Tube Stub x 1/2 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 5/8 in. Tube Stub x 3/8 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 5/8 in. Tube Stub x 1/2 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 5/8 in. Tube Stub x 3/4 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 3/4 in. Tube Stub x 1/2 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 3/4 in. Tube Stub x 3/4 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 3/4 in. Tube Stub x 1 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 1 in. Tube Stub x 3/4 in. Male National Pipe Taper (MNPT) Male Adapter |
SMA 1 in. Tube Stub x 3/4 in. Male National Pipe Taper (MNPT) Male Adapter |
